Testing Area
|
|
Testing points
|
6144 points
|
|
Fixture testing area
|
Max：370mm x 320mm；Min：120mm x 80mm；
|
|
Fixture Format
|
|
Fixture
|
Mason specific fixtures（compatible with fixtures of other format）
|
|
Grid
|
Mason MXD format（compatible with other formats MXA, ETT）
|
|
Testing Parameter
|
|
Insulation testing voltage
|
50V～300V ±10％
|
|
Insulation testing resistance
|
1MΩ～50MΩ±10％（Optional 100 MΩ）
|
|
Conduction testing
|
10Ω～100Ω ±10 ％
|
|
Carbon board testing
|
200Ω～18KΩ±10 ％
|
|
Electronic testing speed
|
3000～4000 points/sec.
|
|
Operating Environment
|
|
Temperature
|
22℃～25℃
|
|
Humidity
|
40%～60%（Non-freezing）
|
|
Power Consumption
|
|
Power
|
AC 220V±5％ 50/60Hz 1 phase 3 wire
|
|
Air source
|
6～8kgf/cm2
|
|
Volume
|
|
Size
|
3300mm（L）x 1500mm（W）x 1630mm（H）
|
